45°彎頭
|
Nominal |
Socket Type |
Structural Diameter |
|
SIZE |
d1 |
d2 |
I |
D |
d |
|
1/2" |
20.3 |
20.1 |
16.0 |
27.0 |
17.0 |
|
3/4" |
25.3 |
25.1 |
19.0 |
33.0 |
23.0 |
|
1" |
32.3 |
32.1 |
22.0 |
41.0 |
29.0 |
|
1-1/4" |
40.3 |
40.1 |
26.0 |
50.0 |
37.0 |
|
1-1/2" |
50.3 |
50.1 |
32.0 |
61.0 |
47.0 |
|
2" |
63.3 |
63.1 |
38.0 |
75.0 |
60.0 |
|
2-1/2" |
75.3 |
75.1 |
44.0 |
92.0 |
72.0 |
|
3" |
90.3 |
90.1 |
51.0 |
110.6 |
87.1 |
|
4" |
110.4 |
110.1 |
61.0 |
127.0 |
106.1 |
|
5" |
140.5 |
140.2 |
77.0 |
162.0 |
133.0 |
|
6" |
160.5 |
160.2 |
86.0 |
186.0 |
154.0 |
|
8" |
200.6 |
200.2 |
130.0 |
240.0 |
185.0 |
