異徑直接
 |
 |
|
Nominal |
Socket Type |
Structural Diameter |
|
SIZE |
d1 |
d2 |
I1 |
d3 |
d4 |
I2 |
D |
d |
L |
|
3/4"*1/2" |
26.45 |
25.42 |
35.0 |
22.40 |
21.52 |
30.0 |
34.0 |
20.0 |
73.50 |
|
1"*1/2" |
32.55 |
31.37 |
40.0 |
22.40 |
21.52 |
30.0 |
41.0 |
20.0 |
79.0 |
|
1"*3/4" |
32.55 |
31.37 |
40.0 |
26.45 |
25.42 |
35.0 |
41.0 |
24.0 |
83.0 |
|
1-1/4"*1/2" |
38.60 |
37.31 |
44.0 |
22.40 |
21.52 |
30.0 |
47.0 |
20.0 |
89.0 |
|
1-1/4"*3/4" |
38.60 |
37.31 |
44.0 |
26.45 |
25.42 |
35.0 |
47.0 |
24.0 |
88.0 |
|
1-1/4"*1" |
38.60 |
37.31 |
44.0 |
26.45 |
25.42 |
35.0 |
47.0 |
30.0 |
93.0 |
|
1-1/2"*1/2" |
48.70 |
47.21 |
55.0 |
22.40 |
21.52 |
30.0 |
58.0 |
20.0 |
103.5 |
|
1-1/2"*3/4" |
48.70 |
47.21 |
55.0 |
26.45 |
25.42 |
35.0 |
58.0 |
24.0 |
105.0 |
|
1-1/2"*1" |
48.70 |
47.21 |
55.0 |
32.55 |
31.37 |
40.0 |
58.0 |
30.0 |
106.0 |
|
1-1/2"*1-1/4" |
48.70 |
47.21 |
55.0 |
38.60 |
37.31 |
44.0 |
58.0 |
36.0 |
108.0 |
|
2"*1/2" |
60.80 |
59.10 |
63.0 |
22.40 |
21.52 |
30.0 |
72.0 |
20.0 |
120.0 |
|
2"*3/4" |
60.80 |
59.10 |
63.0 |
26.45 |
25.42 |
35.0 |
72.0 |
24.0 |
120.0 |
|
2"*1" |
60.80 |
59.10 |
63.0 |
32.55 |
31.37 |
40.0 |
72.0 |
30.0 |
122.0 |
|
2"*1-1/4" |
60.80 |
59.10 |
63.0 |
38.60 |
37.31 |
44.0 |
72.0 |
36.0 |
122.0 |
|
2"*1-1/2" |
60.80 |
59.10 |
63.0 |
48.70 |
47.21 |
55.0 |
72.0 |
46.0 |
132.0 |
|
2-1/2"*2" |
76.60 |
75.30 |
64.0 |
60.80 |
59.10 |
63.0 |
88.0 |
58.0 |
145.0 |
|
3"*2" |
89.60 |
88.29 |
64.0 |
60.80 |
59.10 |
63.0 |
106.0 |
58.0 |
150.0 |
|
3"*2-1/2" |
89.60 |
88.29 |
64.0 |
76.60 |
75.30 |
64.0 |
106.0 |
73.8 |
145.0 |
|
4"*2" |
114.70 |
113.20 |
84.0 |
60.80 |
59.10 |
63.0 |
135.0 |
58.0 |
183.0 |
|
4"*3" |
114.70 |
113.20 |
84.0 |
89.60 |
88.29 |
64.0 |
135.0 |
86.8 |
179.0 |
